How to clean your Franke A300 MS EC Coffee Machine & SU05 Fridge

Step-By-Step Cleaning Guide -A300 MS EC W4 & SU05

Getting Started

Depending on your coffee machine settings, the screen will either prompt you to start a clean cycle based on the time of day, or the number of cups. If that's the case, the screen will prompt you to start, and you can skip the initiation steps below, and go straight to "Start the cleaning process"

However, if you would like to initiate a clean cycle manually, follow the steps below.

Manually commencing a clean cycle

To manually commence a clean cycle, press the Franke logo in the top left corner of the screen.

Enter the pin code 7777 and select OK

Select Cleaning and Maintenance

Select Clean system

The machine will ask if you'd like to clean the system. Select YES to proceed.

Start the cleaning process

During the cleaning process, the coffee machine will guide you through with instructional steps on screen. We've included more detail here to help you make your way through.

Start by opening the door of the coffee machine. To do this, you'll firstly need to remove the grounds container (pictured below) by pulling it out towards you. Set aside.

Opening the door

To open the door, reach inside the door to the left, and press the red lever, which is on the inside of the door as pictured below.

Once the door is open, reinsert the grounds container (leaving the door open) and follow the steps on screen to clean the brewing unit on the inside of the machine.

Cleaning the brewing unit

Start by cleaning the top of the brewing unit with a brush (either the red handled Franke brushes or long handled paint brush supplied at install).

Now, using the long handled brush, brush the brewing unit and piston to remove any loose coffee grounds which have built up.

Once complete, select NEXT. Follow the prompt on screen to remove the grounds container again. If you need to empty it, carefully remove the silver tray attachment (it's magnetic) and set aside, before emptying the coffee grounds into the bin. You can also rinse the container and tray with warm soapy water if necessary. Reassemble and set aside.

Brush out any loose grounds inside the machine and wipe with a damp cloth if necessary.

Select NEXT.

Cleaning the mixer system

The machine will now prompt you to clean the mixer system, which is responsible for producing your powdered beverages.

To remove the mixer chamber, firstly disconnect the powder dosing hose by pulling it towards you. For new machines, it may be a little stiff, just wiggle it until it loosens.

The mixer chamber is locked in place by the red locking mechanism at the base of the chamber. To remove it, you'll need to first unlock it by pushing the red locking handle to the right to the OPEN position.

Once unlocked, remove the mixer chamber by pulling it towards you, away from the door.

The mixer chamber on on the A300 MS EC is made up of three pieces. Disassemble and clean with warm water if necessary (powder buildup, etc.) You can then carefully reassemble, aligning each piece to make sure it fits together, and then set aside while you clean the agitator.

Clean the agitator with the red handled cleaning brush to remove any powder buildup if necessary.

Once clean, reassemble the mixer system:

• firstly, reinstall the mixer chamber;
• secondly, lock the red handle; and
• lastly, reconnect the powder dosing hose.

Once complete, the setup should look like the below.

If you have cannot reassemble for any reason or have trouble closing the door after reassembling, please call us on1800-975-133 to assist, otherwise you may risk a service issue if not reinstalled correctly.

Once complete, insert the grounds container and select NEXT.

Cleaning the spout

The screen will now prompt you to remove the spout and spout insert to clean and then reassemble. Follow the steps outlined in the following images before moving on.

To remove the spout, firstly remove the spout cover by gently pulling it off and away from the machine. Set aside.

The spout is highlighted in red below. To remove it, unplug it from it's coupling by pulling down.

The spout insert is highlighted in red below. To remove it, unplug it from it's coupling by pulling down in the same way as before.

Clean both pieces with warm water, and then reassemble in reverse order. Start by reinserting the spout insert, and then the spout, and then finally replacing the spout cover which should click back into place.

Cleaning the drip grid, drip tray, and waste tray

Now it's time to clean the drip grid and drip tray. Start by removing the waste tray by gently lifting it up slightly and then pulling it out towards you.

You may get an error on screen, that's okay - it's the coffee machine sensor recognising that the drip tray is no longer in place. Continue with emptying and cleaning if necessary.



Once you've removed, you can clean both the drip grid and drip tray if there is a build of coffee or milk solids. Simply wipe and rinse with warm soapy water if required, and then reassemble.

There is a sensor at the back of the tray. Ensure this is dry when reinserting, so the machine recognises the tray is back in place.

Once complete, reinsert the waste tray by gently pushing it back in place. If you're unsure, you can check underneath that it is secured in place.

Once complete, insert one Franke cleaning tablet into the dedicated chute above the machine.

The screen will now guide you through the steps to remove the milk container and insert the cleaning container.

Start by opening the cooling unit or fridge door, then remove the milk container by pulling it out towards you gently. Use two hands if necessary to avoid spilling any milk.

If necessary, rinse the milk container with warm water. If the container is clean and full of fresh milk, simply set aside in your kitchen fridge for the remainder of the clean cycle.

Now insert the blue cleaning container and connect the suction hose to the nipple as shown below.

Now place the collecting container under the spout  to collect any waste water dispensed during the clean cycle.

The machine will run a short rinse and empty the contents into the blue cleaning container once complete.

Empty the liquid from the cleaning container (if any) into the sink. The screen will now prompt you to dose the required amount of Franke cleaning solution ("Reiniger fur Milchsysteme") .

• If the cleaning solution bottle is already open, skip to "Dosing the cleaning solution"
• If the cleaning solution bottle is not yet open, follow the steps to open it

Opening the cleaning solution

Unscrew the plastic cap on the left hand side of the bottle. There will be a red  and white seal on the bottle.

Remove the seal completely by peeling it off. Discard. The bottle will now be open.

Dosing the cleaning solution

You will require 50ml of cleaning solution for the clean cycle. To dose the correct amount, gently squeeze the bottle, until the chamber in the top fills to the 50ml line as shown below.

Now pour the 50ml into the empty blue cleaning container. If you've accidentally dosed more, only use the 50ml required.

Insert the blue cleaning container into the fridge, making sure the hose is attached to the nipple.

Automatic Clean Cycle (8-10 mins)

The machine will now commence the automatic clean cycle. It takes approximately 8-10 minutes. You can leave the machine unattended during this time.

Once the clean cycle is complete, the screen will prompt you with an E676 Cleaning Complete message on screen. Follow the steps below to return to the main menu.

• Remove the collecting container and empty the contents into the sink. Be careful, the contents may be hot and there is a risk of spilling. Store away.
• Open the cooling unit/fridge door and remove the blue cleaning container. Store away.
• Reinsert the milk container into the cooling unit/fridge.
• Select CONFIRM on screen. The machine will prime the milk lines, and then return to the main menu ready for use

Congratulations! Your clean cycle is now complete and your coffee machine is clean, hygienic and ready to enjoy!
